- Subject
- Electronic instruments
- Item type
- Object
- Primary inscriptions
- 'Cambridge Instrument Company Ltd, England. Universal Galvanometer Shunt'
- Object type
- Galvanometer
- Dimensions
- Height: 114mm Width: 124mm Depth: 138mm Weight: 973g
- Inventory No
- 79117
Description
Instrument model No. 'L-226522'. Instrument is contained within a wooden casing with a Bakelite top panel. Bakelite panel has four screw head terminals. Terminals can control two separate circuits, labelled G1, G2 and T1, T2. A rotating dial in the centre of the panel controls total level of resistance passing through shunt. A depressible button locks current.
