- Subject
- Electronic instruments
- Item type
- Object
- Makers
- Elliott Brothers
- Provenance
- Presented by the Marconi Corporation in 2003.
- Primary inscriptions
- 'DARKE'S / PATENT. / NO.1322' 'ELLIOTT BROS. / LONDON / NO.2592'
- Object type
- Electronic instrument
- Dimensions
- Height: 120mm Width: 178mm Depth: 93mm Weight: 2.5kg
- Inventory No
- 12970
- Accession Number
- 2003-11
Description
Steam Engine Indicator, by Elliott Brothers. The instrument is made of metal and comes in six parts, 2 coils, a large and a small valve, there is also a spanner and metal grid, housed in a wooden box with brass handle. The device records how the pressures in the cylinders of steam and internal-combustion engines change during the operating cycle. Inside the lid is a green baize lined section, which lifts out to reveal a compartment - possibly for papers.
12970.1 - Wooden box, with brass handle and baize line section, which lifts out to reveal a compartment - possibly for papers.
12970.2 - Metal grid, aligned at an angle.
12970.3 - Small metal valve with wooden handle.
12970.4 - Large metal valve, with small wooden handle attached.
12970.5 - Small metal spanner.
12970.6 - 2 metal coils, tightly coiled to centre where the coil opens out.
